Course Work

Diagnosis

Note: You must select a description for the degree of the most severe stenosis in each diseased vessel shown.

Normal
Untitled
Mild disease (<40% diameter reduction)
Moderate disease (40 to 70% diameter reduction)
Severe disease (>70% diameter reduction)
Total occlusion
Filled by collaterals

The correct answer here is Normal.

The RAO Caudal projection demonstrates a normal left coronary system

The LAO/Cranial projection demonstrates a normal, right dominant coronary that bifurcates into the PDA and PLB. From this image it appears that a JR4 catheter was used to engage the right coronary. There may be a kink from the JR4 catheter or some tortuosity in the vessel itself proximally, but this is still within normal limits.
